Trough Mass
STEEL CAST AID supplies full range to Trough/Runner Mass which are tailor made to meet the specific
needs of individual Blast Furnance.The main feature of RILRUN Anhydrous Trough/Runner Mass are:-
- Resistsnce to corrosion from slag.
- Resistance to erosion from Iron
- Strutural Integrity
- Volume Stability
- Thermal Stability & shock Resistance
- Non-wettability to Iron & slag
- Low porosity to resist penetration by metal
RILRUN-T
Chemical Properties
- Al2O3(%) 60 -65
- SiC(%) 10-15
- Fixed Carbon(%) 10-15
- V.M(%) 5-10
Physical Properties
- Bulk Density(gm/cc) 2.5 min.
- CCS at 900 °C/1hr(Kg/cm2) 50 min
- CCS at 1400°C/1hr(Kg/cm2) 60 min
- Grain Size (mm) 5 max
RILRUN-R
Chemical Properties
- Al2O3(%) 60 -65
- SiC(%) 15-20
- Fixed Carbon(%) 8-12
- V.M(%) 7-10
PHYSICAL PROPERTIES
- Bulk Density(gm/cc) 2.5 min.
- CCS at 900 °C/1hr(Kg/cm) 65 min
-
- CCS at 1400 °C/1hr(Kg/cm) 70 min
- Grain Size (mm) 5 max
