Trough Mass

STEEL CAST AID supplies full range to Trough/Runner Mass which are tailor made to meet the specific needs of individual Blast Furnance.The main feature of RILRUN Anhydrous Trough/Runner Mass are:-

1. Resistsnce to corrosion from slag.
2. Resistance to erosion from Iron
3. Strutural Integrity
4. Volume Stability
5. Thermal Stability & shock Resistance
6. Non-wettability to Iron & slag
7. Low porosity to resist penetration by metal

RILRUN-T

Chemical Properties

• Al₂O₃(%)        60 -65
• SiC(%)          10-15
• Fixed Carbon(%)           10-15
• V.M(%)          5-10

Physical Properties

• Bulk Density(gm/cc)        2.5 min.
• CCS at 900 °C/1hr(Kg/cm²)        50 min
• CCS at 1400°C/1hr(Kg/cm²)           60 min
• Grain Size (mm)         5 max

RILRUN-R

Chemical Properties
• Al₂O₃(%)          60 -65
• SiC(%)          15-20
• Fixed Carbon(%)            8-12
• V.M(%)            7-10

PHYSICAL PROPERTIES

• Bulk Density(gm/cc)              2.5 min.
• CCS at 900 °C/1hr(Kg/cm)              65 min
• CCS at 1400 °C/1hr(Kg/cm)              70 min
• Grain Size (mm)              5 max
