Mudgun Mass
SCA supplies full range to Taphole/Mudgun Mass which are tailor made to meet the specific
requirements of individual Blast Furnances. The main features of RILGUN Anhydrous Taphole/ Mudgun MAss are:-
Quickly visualize long-term high-impact supply chains through vertical expertise. Dynamically impact low-risk high-yield niche markets for clicks-and-mortar growth strategies. Dynamically impact leveraged innovation with granular networks. Seamlessly morph an expanded array of e-tailers after innovative bandwidth. Energistically formulate emerging information after virtual internal or "organic" sources.
- Consistency of structure
- Excellent workability
- Ease of drilling
- High refractoriness
- Low shrinkage & volume stability
- Good resistance to oxidation & slag attack
- Cotrolled coking out time
- Good shell life
RILGUN - 20
Chemical Properties
- Al2O3(%) 20 -25
- SiO2(%) 35-40
- SiC+C(%) 25-30
- V.M(%) 10 max.
Physical Properties
- Bulk Density(gm/cc) 1.7 min.
- CCS at 900 °C/1hr(Kg/cm) 35 min
- CCS at 1400°C/1hr(Kg/cm) 45 min
- Grain Size (mm) 2 max
RILGUN - 30
Chemical Properties
- Al2O3(%) 35 -40
-
- SiO2(%) 20-25
- SiC+C(%) 25-30
- V.M(%) 10 max.
Physical Properties
- Bulk Density(gm/cc) 1.7 min.
- CCS at 900 °C/1hr(Kg/cm) 40 min
- CCS at 1400°C/1hr(Kg/cm) 50 min
- Grain Size (mm) 2 max
RILGUN - 40
Chemical Properties
- Al2O3(%) 40 -45
-
- SiO2(%) 15-20
- SiC+C(%) 25-30
- V.M(%) 10 max.
Physical Properties
- Bulk Density(gm/cc) 1.8 min.
- CCS at 900 °C/1hr(Kg/cm2) 45 min
- CCS at 1400°C/1hr(Kg/cm2) 55 min
- Grain Size (mm) 2 max
RILGUN - 60
Chemical Properties
- Al2O3(%) 50 -55
-
- SiO2(%) 5-10
- SiC+C(%) 25-30
- V.M(%) 9 max.
Physical Properties
- Bulk Density(gm/cc) 2.0 min.
- CCS at 900°C/1hr(Kg/cm2) 55 min
- CCS at 1400°C/1hr(Kg/cm2) 55 min
- Grain Size (mm) 2 max
