Mudgun Mass

SCA supplies full range to Taphole/Mudgun Mass which are tailor made to meet the specific requirements of individual Blast Furnances. The main features of RILGUN Anhydrous Taphole/ Mudgun MAss are:-

Quickly visualize long-term high-impact supply chains through vertical expertise. Dynamically impact low-risk high-yield niche markets for clicks-and-mortar growth strategies. Dynamically impact leveraged innovation with granular networks. Seamlessly morph an expanded array of e-tailers after innovative bandwidth. Energistically formulate emerging information after virtual internal or "organic" sources.

1. Consistency of structure
2. Excellent workability
3. Ease of drilling
4. High refractoriness
5. Low shrinkage & volume stability
6. Good resistance to oxidation & slag attack
7. Cotrolled coking out time
8. Good shell life

RILGUN - 20

Chemical Properties

• Al₂O₃(%)        20 -25
• SiO₂(%)        35-40
• SiC+C(%)     25-30
• V.M(%)        10 max.

Physical Properties

• Bulk Density(gm/cc)           1.7 min.
• CCS at 900 °C/1hr(Kg/cm)         35 min
• CCS at 1400°C/1hr(Kg/cm)        45 min
• Grain Size (mm)        2 max

RILGUN - 30

Chemical Properties

• Al₂O₃(%)      35 -40
• SiO₂(%)       20-25
• SiC+C(%)     25-30
• V.M(%)        10 max.

Physical Properties

• Bulk Density(gm/cc)          1.7 min.
• CCS at 900 °C/1hr(Kg/cm)          40 min
• CCS at 1400°C/1hr(Kg/cm)         50 min
• Grain Size (mm)          2 max

RILGUN - 40

Chemical Properties

• Al₂O₃(%)      40 -45
• SiO₂(%)       15-20
• SiC+C(%)     25-30
• V.M(%)        10 max.

Physical Properties

• Bulk Density(gm/cc)          1.8 min.
• CCS at 900 °C/1hr(Kg/cm²)          45 min
• CCS at 1400°C/1hr(Kg/cm²)         55 min
• Grain Size (mm)          2 max

RILGUN - 60

Chemical Properties

• Al₂O₃(%)      50 -55
• SiO₂(%)       5-10
• SiC+C(%)     25-30
• V.M(%)        9 max.

Physical Properties

• Bulk Density(gm/cc)          2.0 min.
• CCS at 900°C/1hr(Kg/cm^{2)          55 min}
• CCS at 1400°C/1hr(Kg/cm²)         55 min
• Grain Size (mm)          2 max
